Equip Brack, TV 23"-42" Fixed Slim Wall

l Overview The equip® TV Wall Mount Bracket is a compact but sturdy product that ensures a reliable installation of your LCD/Plasma TV. Follow the graphic guide included in the package, you can install your TV on your own with ease. The wall bracket fits most of the wall materials- brick, concrete and wood, making the ideal choice for you to set up your screens. l Key Features – Tool free tilt adjustment – VESA standards compliant l Specification Material Steel Surface Finished Powder Coating Color Black Dimension 230x230x35mm Sheet Metal Thickness Panel T=1.5mm, Wall PanelT=2mm Suggested Screen Size 23″ – 42″ Support Curved TV No Load Capacity 25KG VESA Mount Standard 75×75, 100×100, 200×100, 200×200 Max. VESA 200x200mm Mounting Hole Pattern Standard VESA Distance to Wall 34mm Screen Freely Tilting Yes Tilt Range +3° ~ -12° Panel Type Detachable Panel Free Height Adjustable No Installation Single Stud Wall Plate Type Fixed Wall Plate Cable Management No l Package Contents – 1 x Wall Mount Bracket – 1 x Screw Pack – 1 x Quick Installation Guide
